Autel Mapper

Autel Mapper

Autel Mapper

Technical Specifications

Autel Smart Controller V2
  • Autel Mapper Specifications
    Operating System Windows 10 or later (64-bit)
    Type
    		 2D/3D Reconstruction
    Computer Specifications
    		 Minimum
    		 Recommended
    CPU
    		 Intel Core i5 8 series or AMD Ryzen 5 3000 series
    		 Intel Core i7 11 series or newer or AMD Ryzen 7 5000 series or newer
    GPU
    		 NVIDIA GeForce GTX1070
    		 NVIDIA GeForce RTX 2080 Ti or higher
    VRAM
    		 6GB
    		 8GB or higher
    RAM
    		 16GB
    		 32GB or higher
    Storage
    		 200GB of usable hard drive space
    		 256GB SSD + 2TB Enterprise HDD
    Display
    		 1280x1024
    		 1920x1080 or higher

  • Function and Performance Specifications
    Maximum Processable Images (One Node) 30,000

  • 3D Reconstruction
    Standalone Task
    		 500 images/1GB free memory
    Standalone Time Required
    		 10,000 images in 18 hours
    (Image collected by EVO II Pro RTK V3, tested by importing into high-performance workstation, processed on "high")
    Accuracy
    		 Centimeter level (1:500 mapping accuracy)
    Output Format
    		 B3DM, OSGB, OBJ, PLY

  • 2D Reconstruction
    Standalone Task 500 images/1GB free memory
    Standalone Time Required 8000 sheets in 6 hours
    (Results obtained after importing images collected by EVO II Pro RTK V3 into high-performance workstation, processed on "high")
    Accuracy
    		 Centimeter level (1:500 mapping accuracy)
    Output Format
    		 GeoTIFF

  • Quick Stitching
    Output Format DOM, DSM, 2.5D visualization
    Supported Output Platforms
    		 App, Autel SkyCommand Center, third-party platforms
    Stitching Methods On-the-fly stitching, Rapid processing

  • Aerial Triangulation
    Pass Rate 0.98
    Output Format
    		 XML

  • Dense Point Clouds
    Output Format PNTS, LAS, XYZ

  • Rebuild Optimization
    KML Import Support
    		 √
    Model Reconstruction Processing
    		 √
    Camera Parameters
    		 √
    Image POS Data Management
    		 √
    Ground Control Point (GCP) Management
    		 √
